Description
Fast and simultaneous Carbon Nitrogen analyses
The CN 802 is a robust and flexible combustion analyzer, that works following official reference methods for the determination of carbon and nitrogen in many industrial sectors such as agriculture, environmental, food & feed, and chemical.
The proprietary CNSoftTM software powers the CN 802 and produces unsupervised, simultaneous results in 5 minutes of:
- TC: Total Carbon
- TOC, TIC: Total Organic and Inorganic Carbon (after acidification)
- TN: Total Nitrogen
- C/N Ratio
The CN 802 is a safe analyzer that does not require aggressive chemicals or time-consuming analysis steps. Just prepare your sample and walk away!
Sensitivity and Versatility at its best
The CN 802 enables analysis across a wide range of sample types, including solid, semi-solid, and liquid samples.
It accommodates large weights and volumes, and it is suitable both for inhomogeneous samples and those with low concentration levels.
The CN 802 ensures high-precision results and excellent reproducibility with:
- A carbon limit of detection ranging from very few ppm to 150 mgC;
- The lowest LOD for Nitrogen;
- A relative standard deviation (RSD) lower than 0.5% (EDTA).
Capable of processing up to 117 samples at a time, the VELP C/N elemental analyzer boasts exceptional efficiency, enabling the highest sample throughput. This is made possible by the electronic autosampler and balance connection to the PC for direct weighing data transfer.
Laboratories have the option to select between Helium and Argon as the carrier gas. Additionally, with dedicated accessories, kits, and tin cups, you can easily analyze liquid samples with high sensitivity and accuracy.
Efficiency for your lab
CN 802 analyzes samples of up to 1 g, effectively reducing the cost-per-analysis through VELP combustion technology and the use of genuine consumables with extended lifetimes.
- The maintenance-free, non-dispersive HighSensIRTMdetector ensures consistent performance over time for the analysis of high and low carbon content samples;
- The CN 802 LoGasTM TCD works with no reference gas ensuring the lowest gas consumption on the market;
- The possibility to seamlessly switch to argon prevents helium availability issues;
- Optimized combustion leads to very low oxygen consumption: when utilizing a pre-installed method, the instrument accurately doses the gas to ensure full sample combustion based on its weight and matrix, saving resources;
- The DriStepTM physical water trap not only requires no maintenance but also removes 99% of water without the need for chemicals;
- The installation of the CN 802 is straightforward, and its compact design saves valuable bench space in your lab.
The combustion technology drastically improves productivity and eliminates the use of chemicals compared to wet chemistry N/protein determination methods.
CN 802 Working Process
Water separation is performed in 2 steps. The combustion gases are carried to the first maintenance-free physical trap DriStepTM (WT1), strategically placed after combustion, trapping 99% of water. Secondly, a chemical trap (WT2) ensures complete removal of the remaining 1% of water.
The combination of high temperature and the exclusive VcopperTM reduces nitrogen dioxide to molecular nitrogen inside the reduction furnace.
The VELP HighSensIR detector enables analysis of an extremely wide carbon concentration range, from just a few ppm up to 150 mg of absolute carbon, from micro to macro applications.
Then, Auto-regenerative CO2 absorbers trap carbon dioxide, allowing the exclusive TCD (Thermal Conductivity Detector) to detect the Nitrogen content.
Intuitive interactions with CNSoft™
Featuring a user-friendly interface, CNSoftTM provides comprehensive information at a glance, including results, database, and instrument conditions.
Users have access to a rich library of pre-installed methods and the ability to create customized ones. An easy calibration curve creation for Carbon and Nitrogen allows for the testing of any sample matrix with no memory effect.
Run a comprehensive Leak Test either across the entire circuit or targeted by zone, following consumable replacement, for instance.
The CN 802 software can be upgraded with the optional 21 CFR Part 11 Package for Pharmaceutical, Cosmetic, and Food industry laboratories that require compliance with FDA regulations.
Enhancing automation through cloud connectivity
The CN 802, by connecting to the VELP Ermes cloud platform, streamlines routine operations by offering real-time monitoring of your elemental analyzer from anywhere, at any time.
Designed for seamless, continuous operation with fully automated processes, VELP Ermes enables the management of multiple instruments, consumables, and workflows, significantly reducing diagnostic time. Indeed, you can check historical records of instrument activities and obtain valuable troubleshooting information as well as grant access to our experts for timely and remote technical and analytical assistance. This ensures a superior level of service while maintaining maximum data security and protection.
Immediate notifications and alerts keep you constantly informed about the status of your analyses. With remote interruption capabilities, you gain complete control over your processes, ensuring maximum safety.
Securely access your instrument’s database via the VELP Ermes platform and collaborate with colleagues to create and share reports seamlessly from your PC, smartphone, or tablet.
